تفاصيل المنتج:
|
| مادة: | معدن | معدل البيانات: | 622 متر حتى 15 جيجابت في الثانية |
|---|---|---|---|
| وقت الصعود والهبوط (20٪ إلى 80٪): | 18 ~ 23ps | ارتعاش إخراج البيانات (RMS): | 1.5 (10.3125g أسفل) ps |
| نموذج: | U9210E | ||
| إبراز: | 12-channel BERT tester 622M to 15G,parallel test bit error rate tester,15G BERT tester with full rate coverage,parallel test bit error rate tester,15G BERT tester with full rate coverage |
||
Equipped with advanced technology and innovative design, the BERT Tester U9210E provides precise measurements and analysis for a wide range of applications. Whether testing signal integrity, evaluating system performance, or troubleshooting communication issues, this versatile device delivers reliable results with unmatched efficiency.
With its user-friendly interface and intuitive controls, the BERT Tester U9210E offers ease of operation for professionals at all levels of expertise. Its comprehensive features and customizable settings make it adaptable to various testing requirements, ensuring accurate and repeatable results every time.
Engineered to meet the highest industry standards, the BERT Tester U9210E is a trusted solution for organizations seeking cutting-edge testing equipment. Its proven performance and robust construction make it a valuable asset for R&D labs, manufacturing facilities, and quality assurance departments.
| No. |
parameter |
minimum |
typical |
maximum |
unit |
| 1 |
Data rate |
0.622 | 0.622,1.25,2.125,2.488,2.5,3.07,3.125,4.25,5.0,6.144,6.25,7.5,8.5 ,9.953,10.00,10.3125,10.52,10.709,11.09,11.32,11.7,14.025,15 | 15 | Gbps |
| 2 |
Code type |
PRBS7,PRBS9,PRBS15,PRBS23,PRBS31 | |||
| 3 |
Rise and fall time (20% to 80%) |
18 | 23 | ps | |
| 4 |
Pattern reversal |
Supports signal reversal at the receiving end |
|||
| 5 |
Signal output amplitude (single-ended) |
200 | 800 | 1000 | mV |
| 6 |
Data output jitter (RMS) |
1.5 (10.3125G down) |
ps | ||
| 7 |
Data input/output interface |
Differential, AC coupling, 50 ohm impedance, SMA |
|||
| 8 |
Clock output |
100 | 156.25 | 156.25 | MHz |
| 9 |
Data signal input sensitivity (single-ended) |
0.1 | Vpp | ||
| 10 |
Data output eye graph intersections |
50 | 52 | 54 | % |
| 11 |
Operating temperature |
10 | 25 | 50 | °C |
When it comes to testing and validating high-speed communication systems, the YOUCii U9210E BERT Tester is an indispensable tool that excels in various product application occasions and scenarios. As a leading brand in the industry, YOUCii has developed the U9210E model in CHINA, ensuring top-notch quality and performance.
Overall, the YOUCii U9210E BERT Tester is a versatile and efficient tool that caters to the demanding needs of professionals in the field. With its advanced features, precise measurements, and robust construction, the U9210E model proves to be a valuable asset for testing signal integrity and data rates in high-speed communication systems.
